For a smoother profile, the frame on Gebo standard hatches has been extended to fit flush against the base mounting. The base mounting screws are covered by the frame for a smoother appearance and extra safety. Deep grooves in the lower frame provide a 100% watertight assembly.

STEPLESS OPENING, TO 180°, PLUS EASY HINGE ADJUSTMENT

Heavy duty friction hinges secure the hatch in any position from ventilation to full 180°. Hinges are also easily adjustable to suit the user.

The Gebo’s unique Airco-Lock theft-proof ventilation setting let fresh air in while the crew rest or when the boat is unattended.

The hatch is locked from the inside, either in the ventilation or the fully closed position.

UNIQUE DEEP-DECK WATER GROOVE

A deep groove in the lower frame keeps water from coming in when the hatch is open.

DIMENSIONS 420 X 420MM HATCH
Overall Size: 475mm x 475mm
Cutout Size: 420mm x 420mm
Flange Depth: 25mm
Height Above Deck 27mm

DIMENSIONS 620 X 620MM HATCH
Overall Size: 500mm x 475mm
Cutout Size: 420mm x 420mm
Flange Depth: 25mm
Height Above Deck 27mm
